Description
Dual Cameras for Cinematic Vlogging from Near to Far
The wide-angle camera delivers 17-stop dynamic range [1] and D-Log 2 [6], while the new 60mm med-tele lens offers 3× optical zoom, up to 12× zoom [8], and natural bokeh for standout portraits.
Powered by a new 1-inch sensor and LOFIC technology, the wide-angle camera delivers 17 stops of dynamic range [1], balancing highlights and shadows even in challenging lighting conditions.
The 60mm med-tele camera offers 3× optical zoom, up to 12× zoom [8], and an f/1.8 aperture for smooth, natural bokeh, adding flattering depth to portraits, lifestyle videos, and creative storytelling.
Unlock the professional D-Log 2 color profile. Capture over a billion colors with 10-bit color depth and smooth gradation, while the high dynamic range gives you greater flexibility in post.
Capture 4K/240fps [2] slow-mo on the wide-angle camera and 4K/200fps [2] on the med-tele camera. Pristine clarity, whether shooting near or far.
4K Live Photo automatically records a 1.5-second clip before and after each shot. Packed with 4K details, every frame feels like a standout moment.
At just 230 g, Osmo Pocket 4P is light in hand and easy to carry. It’s your go-to pocket vlog camera for travel, everyday recording, and quick shoots.
3-Axis Stabilization & ActiveTrack
Up to 12× Zoom
Technical Specifications
General
Dimensions
159.5×63.3×33.5 mm (L×W×H)
Weight
230 g
Number of Microphones
3
Touchscreen
Size: 2.0 inches
Resolution: 556×314
Brightness: 1000 nits
Supported SD Cards
microSD (up to 1 TB)
Recommended microSD Cards
Recommended models:
Lexar Silver Plus 64GB U3 A2 V30 microSDXC
Lexar Silver Plus 128GB U3 A2 V30 microSDXC
Lexar Silver Plus 256GB U3 A2 V30 microSDXC
Lexar Silver Plus 512GB U3 A2 V30 microSDXC
Lexar Silver Plus 1TB U3 A2 V30 microSDXC
Kingston CANVAS GO! Plus 64GB U3 A2 V30 microSDXC
Kingston CANVAS GO! Plus 128GB U3 A2 V30 microSDXC
Kingston CANVAS GO! Plus 256GB U3 A2 V30 microSDXC
Kingston CANVAS GO! Plus 512GB U3 A2 V30 microSDXC
Kingston CANVAS GO! Plus 1TB U3 A2 V30 microSDXC
Gimbal
Controllable Range
Pan: -235° to 58°
Tilt: -125° to 58°
Roll: -45° to 45°
Mechanical Range
Pan: -240° to 90°
Tilt: -130° to 90°
Roll: -85° to 62°
Max Controllable Speed
180.0°/s
Angular Vibration Range
±0.005°
Camera
Sensor
Wide-Angle Lens:
1-inch CMOS
Med-Tele Lens:
1/1.28-inch CMOS
Lens
Wide-Angle Lens:
Format Equivalent: 20 mm
Aperture: f/2.0
Focus Range: 0.09 m to ∞
Med-Tele Lens:
Format Equivalent: 60 mm
Aperture: f/1.8
Focus Range: 0.2 m to ∞
ISO Range
Wide-Angle Lens:
Photo: 100-25600
Video: 100-25600
Low-Light Video: 100-51200
Slow Motion: 100-25600
Med-Tele Lens:
Photo: 50-12800
Video: 50-12800
Low-Light Video: 50-25600
Slow Motion: 50-12800
Electronic Shutter Speed
Wide-Angle Lens & Med-Tele Lens:
Photo: 1/16000-4 s
Video (Auto): 1/16000 s to the limit of frames per second
Video (M): 1/16000-1/4 s
Max Image Size
16:9, 7680×4320
1:1, 6144×6144
Zoom
Digital Zoom
Photo: 7680×4320, 9×
Live Photo: 4K, 9×
Video: 1080p, 12×; 3K, 12×; 4K, 12×
UVC & DP: 4K, 12×
Livestream: 1080p, 12×
Slow Motion/Timelapse: Digital zoom not supported (can only select 1× or 3× optical focal lengths)
Still Photography Modes
Single Shot: Approx. 37 MP
Countdown: Off/0.5/1/2/3/5/10 s
Panorama: 180°, 3×3
Normal Video
4K (16:9): 3840×2160@24/25/30/48/50/60fps
1080p (16:9): 1920×1080@24/25/30/48/50/60fps
3K (9:16): 1728×3072@24/25/30/48/50/60fps
1080p (9:16): 1080×1920@24/25/30/48/50/60fps
Slow Motion
Wide-Angle Lens:
4K (16:9): 3840×2160@100/120/200/240fps
1080p: 1920×1080@120/240fps
Med-Tele Lens:
4K (16:9): 3840×2160@100/120/200fps
1080p: 1920×1080@120/240fps
Hyperlapse
4K/1080p@25/30fps: Auto/×2/×5/×10/×15/×30
Timelapse
4K/3K/1080p@25/30fps
Intervals: 0.5/1/2/3/4/5/6/8/10/15/20/25/30/40/60 s
Duration: 5/10/20/30 mins, 1/2/3/5/10/∞ hours
Motionlapse
4K/3K/1080p@25/30fps
Intervals: 0.5/1/2/3/4/5/6/8/10/15/20/25/30/40/60 s
Duration: 5/10/20/30 mins, 1/2/3/5/10 hours
Supports setting four positions
Low-Light Video
4K (16:9): 3840×2160@24/25/30fps
1080p: 1920×1080@24/25/30fps
Max Video Bitrate
180 Mbps
Supported File System
exFAT
Photo Format
JPEG/DNG/JPEG+DNG
Video Format
MP4 (HEVC)
Built-in Storage Capacity
The camera has 103 GB of built-in storage. The storage capacity can be expanded by inserting a microSD card.
Audio Output
48 kHz 16-bit; AAC
Battery
Type
Li-ion
Capacity
1545 mAh
Energy
11.95 Wh
Voltage
7.74 V
Operating Temperature
0° to 40° C (32° to 104° F)
Charging Temperature
5° to 45° C (41° to 113° F)
Operating Time
210 mins
Tested at room temperature of 25° C (77° F) and 1080p/24fps (16:9), with Wi-Fi off and screen off. This data is for reference only.
Charging Time
18 mins to 80%; 32 mins to 100%
Tested in a laboratory environment with the DJI 65W Portable Charger (sold separately).
Connection
Wi-Fi Operating Frequency
2.400-2.4835 GHz
5.150-5.250 GHz
5.725-5.850 GHz
Wi-Fi Protocol
802.11 a/b/g/n/ac/ax
Wi-Fi Transmitter Power (EIRP)
2.4 GHz:
< 20 dBm (CE/SRRC/MIC)
5.1 GHz:
< 23 dBm (SRRC)
< 20 dBm (CE)
5.8 GHz:
< 23 dBm (SRRC)
< 14 dBm (CE)
Bluetooth Operating Frequency
2.400-2.4835 GHz
Bluetooth Transmitter Power (EIRP)
< 14 dBm
Bluetooth Protocol
BLE 5.4, BR/EDR
Power Consumption
⚡ DJI Osmo Pocket 4P • Electrical & Power Profile
- Operating Voltage: 7.7V DC (Internal Li-ion Battery) / 5V to 12V DC via USB-C Power Delivery (PD)
- Power Draw (Standard 1080p / 4K 30p): ~3.5W
- Power Draw (Active Max / 4K High-Bitrate & Slow-Mo): ~5.0W (While actively recording 4K high-framerate video with 3-axis mechanical gimbal stabilization, ActiveTrack, wireless microphone receiver, and OLED touchscreen enabled)
- Internal Battery Standard: Built-in 1545mAh (11.95Wh) rechargeable Li-ion battery (Supports rapid PD charging: 80% in 18 mins, 100% in 32 mins)
- External Supply Options: Continuous passthrough operation via Extended Battery Handle (~18.5Wh additional capacity), USB-C PD power bank, NP-F USB-C plate, or V-Mount USB-C PD output
⏱️ Estimated Operating Runtimes (5W Active 4K Draw @ 85% Efficiency)
- 🔋 Internal Battery Only (11.95Wh): ~2.0 hours (110 to 130 mins in active 4K; up to ~175–210 mins in 1080p eco mode)
- 🔋 Internal + Extended Battery Handle (~30.5Wh Combined): ~5.2 to 6.5 hours
- 🔋 NP-F 570 (26Wh via USB-C PD Plate): ~4.4 hours (4h 25m external only)
- 🔋 NP-F 770 (47Wh via USB-C PD Plate): ~8.0 hours (7h 59m external only)
- 🔋 NP-F 980 (74Wh via USB-C PD Plate): ~12.6 hours (12h 35m external only)
- 🔋 V-Mount 98Wh (via USB-C PD): ~16.7 hours (16h 40m)
📊 Engineering Note: The 85% Efficiency Standard
- Usable Energy Derating: Published calculations apply a standard 0.85 multiplier (Usable Wh = Rated Wh × 0.85). Compact gimbal cameras enforce an automated low-voltage threshold to preserve microSD file-header closure and prevent clip corruption. The remaining variance accounts for thermal dissipation during USB-C passthrough charging and 3-axis brushless motor torque loads.
⚠️ Production Advisory: To utilize 18-minute rapid PD charging, use a USB-C power source rated at 20W or higher. Continuous 4K high-framerate recording while charging via external USB-C in hot environments can increase chassis temperature.
🛠️ Full Rig Planning: Powering additional accessories from a shared battery pack? Access the interactive FRENEL Power & Battery Runtime Calculator to model cumulative amperage draw across your complete setup.
